The ARB BP-51 Right Rear Bypass Shock Absorber (arbBP5160011R) is a purpose-built suspension upgrade for the 2005–2023 Toyota Tacoma. Designed by ARB's elite Old Man Emu engineering team, this advanced shock absorber features a 51mm bore and internal bypass technology, ensuring unmatched ride quality on both paved roads and rugged off-road terrain.
With an external reservoir for heat management and fully adjustable rebound and compression settings, the BP-51 allows you to fine-tune performance on the fly. Whether you're crawling over rocks or cruising through city streets, this shock delivers a tailored suspension experience that adapts to your driving style and conditions. No cutting or modification required—just bolt it on and go.
Key Features & Benefits:
- Direct bolt-on fit for 2005–2023 Toyota Tacoma models
- Internal bypass with shim-controlled, position-sensitive damping
- Smooth ride at standard height with progressive damping near end travel
- Large 51mm bore and remote reservoir for optimal heat dissipation
- On-vehicle adjustability for compression and rebound
- Hard anodized 6061-T6 aluminum construction resists corrosion and heat
- Polyethylene shaft guard and rubber bushings for added protection
- Made in-house by ARB to the highest quality standards
- Includes a 3-year ARB limited warranty
Technical Specifications:
- Position: Rear Right
- Color: Grey
- Material: 6061-T6 Aluminum
- Open Length: 545mm
- Closed Length: 390mm
- Bore Diameter: 51mm
- Design: BP-51 Internal Bypass with Remote Reservoir
- Construction: Polyethylene Shaft Guard, Rubber Bushings
- CA Prop 65 Warning: No
- Warranty: 3 Years
Vehicle Fitment:
Compatible with the following 2005–2023 Toyota Tacoma trims and configurations:
- Base (2.7L I4, 4.0L V6, 3.5L V6) – 2, 3, and 4-door
- Pre Runner (2.7L I4 & 4.0L V6)
- SR / SR5 (2.7L I4 & 3.5L V6)
- TRD Sport / TRD Off-Road / TRD Pro (3.5L V6 & 4.0L V6)
- Limited / Nightshade / X-Runner / Trail / Edición Especial / Sport
Note: This is the passenger-side (right) rear shock. For the driver-side, see part number arbBP5160011L.
