IE Audi 3.0T Performance ECU Tune | Fits B8/B.5 S4. S5, C7 A6, A7, Q5

Unlock the performance potential of your Audi with the Integrated Engineering (IE) 3.0T Supercharged Performance ECU Tune, developed for compatible Audi B8/B8.5 S4, S5, C7 A6, A7, and Q5 applications equipped with the supercharged 3.0T engine.

Engineered using Integrated Engineering's motorsport experience and advanced ECU calibration technology, this performance software transforms the factory engine management system to deliver substantial horsepower and torque gains. Depending on the selected calibration, fuel, and supporting hardware, IE advertises performance figures reaching up to 548 horsepower and 525 ft-lbs of torque.

With more than 5,000 vehicles tuned according to the manufacturer, IE's Audi 3.0T tuning platform provides multiple upgrade paths designed to accommodate different performance goals. Drivers can begin with a Core Tune on factory pulleys before progressing to Single Pulley, Dual Pulley, and upgraded throttle body configurations.

The IE POWERlink Mobile platform makes ECU tuning more convenient by allowing supported vehicles to be flashed directly through a compatible Apple or Android smartphone. Users can select available fuel calibrations, upgrade their software as additional hardware is installed, perform diagnostics, and monitor live vehicle data.

Beyond conventional horsepower and torque improvements, the tuning platform offers available motorsport-oriented features, including 2-step launch control, exhaust crackles, manual fan control, and fuel drain functionality. Feature availability depends on the selected calibration and vehicle configuration.

Whether you're upgrading a daily-driven Audi or developing a high-performance supercharged build, the Integrated Engineering 3.0T ECU Tune provides a flexible tuning solution designed to maximize the capabilities of the Audi 3.0T platform.

Key Features

• Brand: Integrated Engineering (IE)

• Product: Audi 3.0T Supercharged Performance ECU Tune

• Maximum Advertised Output: Up to 548 HP and 525 ft-lbs of torque.

• Developed for compatible Audi 3.0T supercharged applications.

• More than 5,000 vehicles tuned, according to Integrated Engineering.

• Multiple performance calibrations for different hardware configurations.

• Core Tune for factory pulley configurations.

• Single Pulley and Dual Pulley tuning options.

• Supports compatible upgraded throttle body configurations.

• Maximizes horsepower and torque potential.

• Improved acceleration and engine response.

• Supports multiple fuel-octane calibrations.

• Available E40 ethanol performance calibration.

• IE POWERlink Mobile tuning support.

• Compatible with supported Apple and Android devices.

• Convenient at-home ECU flashing.

• Supports software upgrades as additional performance hardware is installed.

• Provides diagnostic functionality.

• Supports live vehicle gauge monitoring.

• Available 2-step launch control.

• Available exhaust crackle functionality.

• Available manual fan control.

• Available fuel drain functionality.

• Motorsport feature availability depends on the selected software and vehicle configuration.

Available ECU Tune Configurations

IE Core Tune – Factory Pulley Configuration

The IE Core Tune is designed to deliver a substantial performance increase while retaining the factory supercharger pulley configuration.

This calibration provides an excellent starting point for Audi enthusiasts seeking additional horsepower, torque, and improved acceleration without immediately upgrading the supercharger drive system.

Advertised Performance:

• 91 AKI / 95 RON: 403 HP / 387 ft-lbs.

• 93 AKI / 98 RON: 416 HP / 391 ft-lbs.

IE Single Pulley Tune

The IE Single Pulley Tune is calibrated for vehicles equipped with a compatible 57.5 mm supercharger pulley upgrade.

By increasing the supercharger's operating speed, the upgraded pulley configuration supports additional boost and increased performance when paired with the appropriate ECU calibration.

Advertised Performance:

• 91 AKI / 95 RON: 422 HP / 416 ft-lbs.

• 93 AKI / 98 RON: 435 HP / 423 ft-lbs.

Required Hardware: Compatible 57.5 mm supercharger pulley configuration.

IE Dual Pulley Tune

The IE Dual Pulley Tune is developed for compatible upgraded supercharger drive configurations utilizing a 207 mm crank pulley.

This performance stage provides substantial horsepower and torque gains, with additional fuel-specific calibrations available for enthusiasts seeking maximum output.

Advertised Performance:

• 91 AKI / 95 RON: 444 HP / 459 ft-lbs.

• 93 AKI / 98 RON: 453 HP / 469 ft-lbs.

• 100 AKI / 104 RON: 511 HP / 498 ft-lbs.

• 104 AKI / 108 RON: 519 HP / 508 ft-lbs.

• E40 Ethanol: 534 HP / 520 ft-lbs.

Hardware Configuration: Compatible dual-pulley setup with a 207 mm crank pulley.

IE Dual Pulley Tune – Upgraded 80 mm Throttle Body

For enthusiasts pursuing the highest advertised performance figures, Integrated Engineering offers a Dual Pulley calibration designed for a compatible 80 mm upgraded throttle body configuration.

This setup supports increased airflow and additional performance when paired with the required supporting hardware and appropriate fuel calibration.

Advertised Performance:

• 91 AKI / 95 RON: 452 HP / 462 ft-lbs.

• 93 AKI / 98 RON: 462 HP / 471 ft-lbs.

• 100 AKI / 104 RON: 521 HP / 504 ft-lbs.

• 104 AKI / 108 RON: 534 HP / 513 ft-lbs.

• E40 Ethanol: 548 HP / 525 ft-lbs.

Maximum Advertised Performance: 548 HP and 525 ft-lbs of torque.

These figures represent the supplied manufacturer's performance results. Actual output depends on the vehicle, calibration, fuel quality, installed hardware, and operating conditions.

Motorsport & Advanced Tuning Features

Integrated Engineering's Audi 3.0T tuning platform includes access to additional performance-oriented software features, subject to calibration and vehicle compatibility.

Available Features:

• 2-Step Launch Control – Motorsport-oriented launch functionality.

• Exhaust Crackles – Available exhaust sound calibration.

• Manual Fan Control – Additional control over compatible cooling functions.

• Fuel Drain – Supported fuel-management functionality.

• Fuel Calibration Switching – Select compatible maps for different fuel grades.

• Live Gauge Monitoring – View supported vehicle operating parameters.

• Diagnostic Functions – Access supported diagnostic information.

Confirm the availability of individual features for your exact vehicle and selected tune before ordering.

IE POWERlink Mobile Tuning

The IE POWERlink Mobile platform allows compatible Audi owners to access supported tuning and vehicle-management functions through their smartphones.

Using the appropriate IE POWERlink hardware and mobile application, drivers can manage their tuning setup without requiring a traditional workshop ECU flashing procedure.

Supported Platform Features:

• ECU flashing through compatible Apple and Android devices.

• Selection of available fuel calibrations.

• Software upgrades for compatible hardware modifications.

• Diagnostic functionality.

• Live vehicle gauge monitoring.

• Access to supported tuning features.

Note: The required IE POWERlink flashing hardware may be sold separately. Confirm device compatibility, included accessories, and current software requirements before ordering.

Technical Specifications

• Manufacturer: Integrated Engineering

• Product Type: Performance ECU Calibration

• Engine Platform: Audi 3.0T Supercharged

• Available Configurations: Core Tune, Single Pulley, Dual Pulley, and Dual Pulley with upgraded throttle body

• Maximum Advertised Horsepower: 548 HP

• Maximum Advertised Torque: 525 ft-lbs

• Supported Fuel Calibrations: 91, 93, 100, and 104 AKI, plus E40 where available

• Single Pulley Configuration: 57.5 mm supercharger pulley

• Dual Pulley Configuration: 207 mm crank pulley

• Upgraded Throttle Body Configuration: 80 mm

• Flashing Platform: IE POWERlink Mobile

• Mobile Compatibility: Supported Apple and Android devices

• Diagnostics: Supported

• Live Gauge Monitoring: Supported

• Motorsport Features: Available according to calibration and vehicle compatibility

Fitment

Designed for compatible Audi vehicles equipped with the 3.0T Supercharged engine.

Audi S Models:

• Audi S4 B8 3.0T Supercharged

• Audi S4 B8.5 3.0T Supercharged

• Audi S5 B8 3.0T Supercharged

• Audi S5 B8.5 3.0T Supercharged

Audi A Models:

• Audi A6 C7 3.0T Supercharged

• Audi A7 C7 3.0T Supercharged

Audi SUV Applications:

• Audi Q5 3.0T Supercharged

Important Fitment Note: Exact compatibility depends on the model year, engine code, ECU software version, transmission configuration, and regional vehicle specification.

Confirm your vehicle against Integrated Engineering's supported application list before ordering. Do not assume compatibility with the updated CREC engine, turbocharged 3.0T variants, or other Audi platforms unless explicitly confirmed by the manufacturer.

Installation & Compatibility Notes

• Verify compatibility with your exact Audi model, engine code, and ECU software.

• Confirm that the required IE POWERlink flashing hardware is available.

• Select the correct ECU calibration for your installed hardware configuration.

• Core Tune is intended for compatible factory pulley configurations.

• Single Pulley software requires the appropriate 57.5 mm supercharger pulley setup.

• Dual Pulley software requires the matching upgraded supercharger drive configuration.

• The 80 mm throttle body calibration requires compatible supporting hardware.

• Use only fuel that meets the selected calibration's octane or ethanol requirements.

• Confirm whether additional transmission tuning is recommended for your selected performance stage.

• Supporting cooling, intake, and drivetrain modifications may be necessary depending on your performance goals.

• Follow Integrated Engineering's current installation and tuning instructions.

Important Tuning Compatibility & Disclaimers

• Advertised horsepower and torque figures are based on Integrated Engineering's supplied performance results.

• Maximum advertised output requires the appropriate performance calibration, fuel, and supporting hardware.

• E40 ethanol calibrations require fuel that meets the manufacturer's specified ethanol-content requirements.

• Never use a higher-octane calibration with fuel that does not meet its minimum requirements.

• Motorsport software features may not be available for every vehicle or calibration.

• ECU tuning can affect emissions compliance, warranty coverage, component stress, and vehicle reliability.

• Confirm applicable local regulations before installing performance software or aftermarket hardware.

• Verify exact tuning and hardware compatibility with Integrated Engineering before purchasing.
