Description
The CANchecked Audi 8L A3 / S3 Pre-Facelift MFD32 Multi Function Display is a compact and configurable 3.2-inch digital display designed specifically for Audi 8L A3 and S3 Pre-Facelift models. The CANchecked MFD32 Gen2 integrates into the vehicle's ventilation area, providing a clean, vehicle-specific installation while allowing airflow to pass around the display.
Designed for enthusiasts and tuners, the MFD32 Gen2 provides detailed vehicle data through CAN Bus integration, while offering customizable display pages, touchscreen navigation, additional sensor inputs, configurable alarms, data logging, and an integrated Performance Meter.
The touchscreen interface allows intuitive swipe navigation between pages, while the display can be customized with personal layouts, images, and startup animations. Up to four analog inputs and an ethanol sensor can be connected directly to the display for expanded monitoring capabilities.
The integrated CAN Switching function allows the display to operate as a keypad and send custom CAN messages to the vehicle's CAN Bus. The Performance Meter can measure 0-100, 100-200, and 0-200 acceleration times without additional hardware, while customizable alarms can provide prominent warnings when monitored parameters exceed configured limits.
The CANchecked MFD32 Gen2 can also be fully customized using the CANchecked DSS, providing a flexible and integrated solution for displaying important vehicle information in the Audi 8L A3 and S3 Pre-Facelift.
Key Features
- Vehicle-specific ventilation insert maintains airflow around the display
- 3.2-inch MFD32 Gen2 touchscreen display
- CAN Bus integration for detailed vehicle data
- Gear display via CAN Bus or calculated using speed and RPM
- Touchscreen navigation with intuitive swipe gestures
- Customizable display pages
- Custom images and startup animations
- Supports up to 4 analog inputs
- Direct ethanol sensor connection
- CAN Switching for sending custom CAN messages
- Display can function as a keypad through CAN Switching
- Customizable alarms and warning messages
- Internal SD card data logging
- Integrated Performance Meter
- Measures 0-100, 100-200, and 0-200 acceleration times
- Automatic display dimming synchronized with the instrument panel
- CANchecked DSS compatibility for display customization
- Designed for straightforward DIY installation
Specifications
- Brand: CANchecked
- Product: MFD32 Multi Function Display
- Generation: Gen2
- Display Size: 3.2 inches
- Display Type: Touchscreen
- Vehicle Integration: Audi 8L-specific ventilation insert
- Vehicle Application: A3 / S3 Pre-Facelift
- Vehicle Side: Left-Hand Drive (LHD)
- Communication: CAN Bus
- Additional Inputs: Up to 4 analog inputs
- Ethanol Sensor Support: Yes
- CAN Switching: Yes
- Data Logging: Internal SD card
- Performance Meter: 0-100, 100-200, 0-200
- Automatic Dimming: Yes
- Display Customization: CANchecked DSS
- Connector A: 8-way Molex
- Connector B: 10-way Molex
- Connection Cables: Pre-assembled, 20 cm
- Cable Applications: Power supply, CAN Bus, analog inputs, 5V, sensor ground
What’s Included
- CANchecked MFD32 Gen2 3.2-inch display integrated into the ventilation insert for LHD vehicles
- Connector A, 8-way Molex
- Connector B, 10-way Molex
- Different-colored pre-assembled 20 cm connection cables for power supply, CAN Bus, analog inputs, 5V, and sensor ground
- Pins for crimping
- USB data cable
Vehicle Fitment
Audi
- Audi A3 8L Pre-Facelift — LHD
- Audi S3 8L Pre-Facelift — LHD
Vehicle Compatibility & Data Availability
CANchecked products communicate directly with the vehicle through the CAN Bus. CAN Bus became widely available in production vehicles from approximately 2008 onwards, but compatibility and available data depend on the vehicle manufacturer, model, model year, installed control units, and software version.
Many modern vehicles provide limited information through standard OBD diagnostics. For selected vehicles, CANchecked offers dedicated integrations that can access additional vehicle data directly from internal vehicle communication networks. Available functions and parameters may vary between vehicles, including vehicles within the same model range.
Not all displayed values are intended for diagnostic or safety-critical purposes. Displayed data should not be relied upon as the sole source for vehicle operation, diagnostics, maintenance, tuning, or safety-related decisions.
Customers are responsible for verifying compatibility with their specific vehicle before purchase and installation.
